PRODUCT DESCRIPTION

Blum 70T3550.TL CLIP Top 110° Overlay Unsprung Screw-On Hinge – Nickel

The Blum 70T3550.TL is an unsprung CLIP top concealed hinge for full-overlay cabinet doors. Its free-moving action makes it particularly suitable for handleless doors operated by Blum TIP-ON.

Unlike a conventional sprung hinge, the 70T3550.TL does not pull the door closed and does not include BLUMOTION soft close. When used with a compatible TIP-ON unit, the door opens with a light press and can then move freely.

The hinge has a screw-on steel cup for secure fixing to the door. Once installed, the CLIP mechanism allows the door to be attached to or removed from a compatible cabinet-side mounting plate without tools.

Key features

Genuine Blum CLIP top concealed hinge
Blum part number: 70T3550.TL
Hart Wholesale stock code: HI70T3550TL
Designed for full-overlay cabinet doors
110° opening angle
Unsprung, free-moving hinge action
Suitable for Blum TIP-ON handleless door applications
Screw-on steel hinge cup
Standard 35mm hinge-cup drilling
Tool-free CLIP door attachment and removal
Three-dimensional door adjustment with a suitable mounting plate
Convenient spiral-screw depth adjustment
Nickel-plated steel construction
Suitable for cabinet doors up to 24mm thick
Supplied as one hinge

Technical specifications

application	standard hinge
Cranking	Overlay application
Opening angle	110
Closing mechanism	unsprung
hinge variant	with free movement for TIP-ON
Cover cap type	90M2503
Cover cap type	70.1503
Cover cap type	70T3504 – boss cover cap
Boss material	Steel boss
boss finish	Nickel plated
Boss assembly	screw-on
Flange width	57 mm
Flange length	22 mm
Flange height	3.2 mm
diameter hinge boss drilling	35 mm
distance between drillings	45 mm
eccentric position of fixing holes to hinge boss hole	9.5 mm
boss drilling depth	13 mm
Minimum drilling distance	3 mm
Maximum drilling distance	7 mm
arm material	Steel
arm finish	Nickel plated
collision measurement (hinge arm height)	21.5 mm
Fixed dimension / factory setting	11 mm
Type of side adjustment	With screw
Side adjustment	+/-2 mm
Type of depth adjustment	convenient with spiral screw
Depth adjustment	+3/-2 mm
Gap	1.5 mm
Item package	1 piece
packaging	Commercial packing
product combination	No

Designed for TIP-ON handleless doors

This hinge has no closing spring, allowing a compatible TIP-ON ejector to push the cabinet door open without working against the hinge mechanism.

Pair it with a suitable Blum TIP-ON short door unit for standard overlay handleless cabinet doors. The TIP-ON unit and its magnetic catch keep the door securely closed until the front is pressed.

This hinge should not be described as a soft-close hinge. For integrated soft closing, choose the Blum 71B3550 overlay BLUMOTION hinge instead.

Screw-on hinge-cup installation

The 70T3550.TL requires a 35mm hinge-cup drilling and two screw-fixing holes positioned on 45mm centres. The steel hinge cup is secured directly to the inside face of the cabinet door using suitable screws.

The screw-on fixing relates to the hinge cup fitted to the door. It does not refer to the cabinet-side mounting plate.

Mounting plate required

This product is supplied as one hinge only. A compatible Blum CLIP mounting plate must be selected and ordered separately. Mounting-plate height and cabinet fixing method should be selected according to the required door overlay and cabinet construction.

Frequently asked questions

Does the 70T3550.TL include soft close?

No. This is an unsprung, free-moving hinge without integrated BLUMOTION. Choose the 71B3550 if integrated soft closing is required.

Does this hinge pull the cabinet door closed?

No. The 70T3550.TL has no closing spring. It is designed to move freely, making it suitable for TIP-ON handleless door applications.

What does full overlay mean?

Full overlay means the closed cabinet door sits in front of and covers most of the cabinet side panel. The final overlay depends on the drilling distance, mounting-plate height and hinge adjustment.

Is the TIP-ON unit included?

No. The hinge and TIP-ON opening unit are separate products and must be ordered individually.

Is a mounting plate included?

No. A compatible Blum CLIP cabinet-side mounting plate must be selected and purchased separately.

What drilling is required?

The hinge requires a 35mm cup hole, 13mm deep, with two fixing holes positioned on 45mm centres. The recommended cup drilling distance is 3–7mm.

Can the cabinet door be removed without tools?

Yes. Once the hinge and mounting plate have been installed, the CLIP mechanism allows the door to be attached and removed without tools.

TECHNICAL DETAILS

Application: Overlay
Finish: Nickel
Colour: Nickel
Material: Steel
