Name: BLUM LEGRABOX BLUMOTION RUNNER FE 40KG 500 PR
Brand: JULIUS BLUM UK LTD
SKU: DR750500SA
Price: 25.39 GBP
Availability: InStock

PRODUCT DESCRIPTION

Blum Legrabox Blumotion Runner FE 40kg 500mm - Pair

The Blum Legrabox Blumotion Runner FE 40kg at 500mm is engineered for deeper drawer configurations where full extension and soft-close performance are both essential. Part of the Legrabox S system, it combines a 40kg load rating with Blum's renowned Blumotion damping for a premium drawer experience.

Load Capacity: 40kg
Depth: 500mm
Finish: Zinc plated
Part Number: 750.5001S
Supplied: Pair (PR)
System: Blum Legrabox S
Brand: Blum

Ideal for deeper kitchen base units, larder drawers, and utility furniture where the extra depth is needed. The Blumotion mechanism ensures consistent, silent closure across the full service life of the drawer.

Technical Specifications

Type of runner system	LEGRABOX cabinet profile
Motion technology	Integrated BLUMOTION / suitable for TIP-ON BLUMOTION / suitable for SERVO-DRIVE
Dynamic load bearing	40 kg
Nominal length	500 mm
Additional features	BLUMOTION / for TIP-ON BLUMOTION
Material	Steel
Colour / finish	Zinc plated
Pull-out type	Full extension
Runner system	Synchronised roller carriage system
Drawer profile width	32.06 mm
Shank height of cabinet profile	47.5 mm
Cabinet profile width	31 mm
Distance of latch	255.5 mm
Distance of BLUMOTION and BLUMATIC	279 mm
Cabinet profile fixing	With screws
Assembly type	Side mounted
Connection runner system with box or drawer	For locking device
Minimum internal cabinet depth	503 mm
Item package	Right + left
Packaging	Commercial packing / Multipack
