1834 × 38 × 1mm Self-Colour Aluminium Continuous Hinge

This light-duty aluminium continuous hinge, also called a piano hinge, measures 1834mm long and 38mm wide when fully open. It has 1mm-thick leaves, a 4mm closed projection and a 2.3mm-diameter stainless-steel pin.

The continuous design supports the hinged edge along its length rather than concentrating movement at several separate hinge positions. It is suitable for appropriately specified cabinets, furniture, boxes, long lids, inspection panels and light-duty doors or enclosures.

There are 62 factory-produced fixing holes per hinge, countersunk for 2.5mm-diameter screws. Fixing screws must be ordered separately and selected to suit the substrate and application.

The hinge has a self-colour natural aluminium finish and requires regular lubrication. Supplied as one complete 1834mm hinge. It may be cut to a shorter length using suitable aluminium-cutting equipment.

Key features

• Light-duty continuous hinge or piano hinge
• Aluminium leaves with stainless-steel pin
• Self-colour natural aluminium finish
• 1834mm overall length
• 38mm open width
• 1mm leaf thickness
• 4mm closed projection
• 2.3mm-diameter pin
• 62 fixing holes per hinge
• Countersunk for 2.5mm-diameter screws
• Regular lubrication required
• May be cut to length
• Supplied as one complete hinge

Specifications

Typical applications

• Cabinet and cupboard doors
• Furniture and fitted joinery
• Storage boxes and long lids
• Equipment cases and enclosures
• Inspection and access panels
• Light-duty doors and screens

Cutting, installation and care

1. Confirm that a light-duty hinge suits the application.
2. Measure and mark the required finished length.
3. Cut with suitable aluminium-cutting equipment and appropriate protective equipment.
4. Remove sharp edges and swarf.
5. Align the complete hinge before marking fixing positions.
6. Use compatible 2.5mm-diameter countersunk screws suited to the substrate.
7. Test movement before final tightening and lubricate regularly.

Fixing screws are ordered separately and must not be advertised as included.

Questions and answers

What size is this hinge?

It measures 1834mm long, 38mm wide when fully open and 1mm thick. Its closed projection is 4mm.

How many fixing holes does it have?

It has 62 fixing holes per hinge. Replace the incorrect existing reference to 52 holes.

What fixings does it accept?

The holes are countersunk for 2.5mm-diameter screws. Select a suitable screw type and length for the substrate.

Are fixing screws included?

No. Fixing screws must be ordered separately.

What is the pin made from?

The 2.3mm-diameter hinge pin is stainless steel.

Is this a heavy-duty hinge?

No. It is classified as light duty. No certified load capacity is declared.

Can the hinge be shortened?

Yes. It may be cut using suitable aluminium-cutting equipment. Remove sharp edges and swarf after cutting.

Does it require maintenance?

Yes. Regular lubrication is required to maintain free movement.

Is it fire rated?

No fire-door rating or security classification is declared for this product.
