2000 × 32 × 0.7mm Nickel-Plated Steel Piano Hinge

This rolled straight piano hinge, also known as a continuous hinge, measures 2000mm long and 32mm wide when fully open. It is manufactured from 0.7mm-thick steel with a nickel-plated silver finish.

The hinge provides continuous support along a long hinged edge, making it suitable for cabinets, cupboards, furniture, boxes, lids, access panels and compatible enclosure applications. Its 2 metre length may be used whole or professionally shortened for the installation.

The rolled construction has a 3.3mm roll width. Factory-drilled 2.5mm fixing holes simplify positioning, while the correct screws must be selected separately for the substrate and intended use.

Supplied as one complete 2000mm hinge length. Fixing screws are not included.

Key features

• Rolled straight piano hinge or continuous hinge
• Steel construction
• Nickel-plated silver finish
• 2000mm overall length
• 32mm open width
• 0.7mm material thickness
• 3.3mm roll width
• Factory-drilled 2.5mm fixing holes
• Continuous support along the hinged edge
• May be cut to the required length
• Supplied as one complete hinge

Specifications

Typical applications

• Cabinet and cupboard doors
• Piano-style lids and long covers
• Furniture and fitted joinery
• Storage boxes and equipment cases
• Inspection and access panels
• Suitable doors and enclosures

Why use a continuous hinge?

A continuous hinge supports the hinged edge along its length instead of concentrating movement at several separate hinge positions. This can help distribute movement and maintain alignment across a long door, lid or panel when the hinge and fixings are correctly specified.

Cutting and installation

1. Confirm that the hinge dimensions and steel construction suit the application.
2. Measure and mark the required finished length.
3. Use suitable metal-cutting equipment and appropriate protective equipment.
4. Remove sharp edges and swarf after cutting.
5. Align the hinge before marking the fixing positions.
6. Select suitable screws for the substrate, hole diameter and intended duty.
7. Check alignment and free movement before final tightening.

Fixing screws are not included. Cutting may change the end-hole position, so plan the finished length and fixing layout before modification.

Questions and answers

What size is this piano hinge?

It measures 2000mm long, 32mm wide when fully open and 0.7mm thick.

What is the hinge made from?

It is manufactured from steel with a nickel-plated silver finish. It must not be described as stainless steel.

What does rolled straight mean?

It describes the conventional piano-hinge construction, with straight leaves formed around the central roll.

What is the roll width?

The roll width is 3.3mm.

Does it have fixing holes?

Yes. It has factory-drilled fixing holes measuring 2.5mm in diameter.

What screws should be used?

Select screws that suit the 2.5mm fixing holes, substrate and intended duty. No specific screw size is declared for this product.

Are fixing screws included?

No. Fixing screws must be ordered separately.

Can the hinge be shortened?

Yes. It may be cut using suitable metal-cutting equipment. Remove sharp edges and swarf, and account for the revised end-hole position.

Is it load rated or fire rated?

No certified load capacity, fire-door rating or security classification is declared for this product.

Is nickel-plated steel suitable outdoors?

Suitability depends on exposure, maintenance and the installation environment. Do not describe it as corrosion-proof, stainless or marine grade.
