3500 × 32 × 0.7mm Bright Magnetic Stainless Steel Piano Hinge

This rolled straight stainless steel piano hinge, also called a continuous hinge, measures 3500mm long and 32mm wide when fully open. Its square leaves are manufactured from 0.7mm-thick 4016-quality magnetic stainless steel with a bright silver finish.

The hinge uses a steel pin and has a magnetic stainless-steel construction. Magnetism is a normal property of this material and must not be treated as evidence that the leaves are ordinary plated steel.

The factory-produced holes are countersunk for 2.5mm-diameter woodscrews. Fixings must be ordered separately and selected to suit the substrate and intended application.

Supplied as one complete 3500mm hinge length. It may be cut to a shorter required length using suitable stainless-steel cutting equipment. Remove sharp edges and swarf after shortening.

Key features

• Rolled straight piano hinge or continuous hinge
• 4016-quality magnetic stainless-steel leaves
• Steel hinge pin
• Bright silver finish
• 3500mm overall length
• 32mm open width
• 0.7mm leaf thickness
• Square leaf shape
• Countersunk for 2.5mm-diameter woodscrews
• Continuous support along the hinged edge
• May be cut to a shorter length
• Fixing screws ordered separately
• Supplied as one complete hinge

Specifications

Roll diameter, pin diameter, knuckle length, fixing-hole count and hole spacing are not confirmed and must not be advertised.

Typical applications

• Cabinet and cupboard doors
• Furniture and fitted joinery
• Storage boxes and long lids
• Display cases and screens
• Inspection and access panels
• Suitable fabricated assemblies

Cutting and installation

1. Confirm that the hinge material and dimensions suit the application.
2. Support the full 3500mm length before measuring or cutting.
3. Use suitable stainless-steel cutting equipment and protective equipment.
4. Remove sharp edges and metal swarf after cutting.
5. Align the complete hinge before marking fixing positions.
6. Use compatible 2.5mm-diameter countersunk woodscrews suited to the substrate.
7. Test movement and alignment before final tightening.

Questions and answers

What size is this piano hinge?

It measures 3500mm long, 32mm wide when fully open and 0.7mm thick.

What does 4016-quality magnetic mean?

It identifies the magnetic stainless-steel material used for the hinge leaves. Magnetism is normal for this material.

Is it Grade 304 stainless steel?

No. It is specified as 4016-quality magnetic stainless steel and must not be advertised as Grade 304.

What screws does it accept?

The holes are countersunk for 2.5mm-diameter woodscrews. Choose a suitable screw length and material for the substrate.

Are fixing screws included?

No. Fixing screws must be ordered separately.

Can the hinge be shortened?

Yes. Use suitable stainless-steel cutting equipment and remove sharp edges and swarf after cutting.

Is it suitable for marine environments?

No marine-use or exterior corrosion rating is declared. Suitability depends on the environment and maintenance.

Is it fire rated or load rated?

No fire-door rating, security classification or certified load capacity is declared.
