PRODUCT DESCRIPTION
This 270° concealed cup hinge is designed for full-overlay cabinet doors, providing wide-opening access for standard cabinet applications. It features a straight arm with keyhole fixing and a screw-fixed 35 mm cup.
Technical specifications
- Opening angle: 270°
- Door mounting: full overlay
- Arm type: straight, with keyhole fixing
- Material: zinc alloy
- Cup diameter: 35 mm
- Cup drilling depth: 12.5 mm
- Cup fixing: screw fixing
- Drilling pattern: 52/6.5
- Product code: 31250600 (312.50.600)
Installation and ordering
The door requires cup drilling. Use with the 0 mm cruciform mounting plate, code 31256610, ordered separately. Order 3.5 mm countersunk fixing screws separately.
TECHNICAL DETAILS
- Application: Furniture Hinges
- Colour: Nickel
- Material: Zinc
