Name: Blum AVENTOS HS Lift Mechanism I 676–800mm – 20S2I00
Brand: JULIUS BLUM UK LTD
SKU: HI20S2I00
Price: 83.92 GBP
Availability: InStock

PRODUCT DESCRIPTION

The Blum AVENTOS HS 20S2I00.05 Type I lift-mechanism set is the highest-capacity mechanism option for original-generation AVENTOS HS cabinets from 676 to 800 mm high. It forms part of an up-and-over lift system that moves a large single-piece cabinet front upwards and over the cabinet.

The mechanisms incorporate BLUMOTION for soft and controlled closing when installed as part of a correctly specified AVENTOS HS system. Spring-force adjustment allows the completed lift system to be matched to the cabinet height and total front weight, including the handle.

Pack contents

2 x symmetrical AVENTOS HS lift mechanisms
10 x chipboard fixing screws, 4 x 35 mm

Key features

Original-generation Blum AVENTOS HS lift-mechanism set
Type I mechanism for the highest front-weight range in the 676–800 mm cabinet-height group
Creates an up-and-over movement for a single-piece cabinet front
Integrated BLUMOTION for soft and effortless closing
Infinitely adjustable spring force
Mechanisms are symmetrical and can be installed on either cabinet side
Minimum internal cabinet depth: 276 mm
Suitable for correctly configured cabinets up to 1800 mm wide

Front-weight selection

The permitted total front weight changes according to the exact cabinet height. Blum specifies the following reference points for the Type I mechanism:

Cabinet height	Total front weight including handle
676 mm	13.00–21.50 kg
700 mm	12.50–21.50 kg
750 mm	11.50–20.50 kg
800 mm	10.50–20.00 kg

These are reference points rather than one continuous weight range. Blum provides separate values at 5 mm cabinet-height intervals. Use the Blum Product Configurator to verify the correct mechanism for the precise cabinet height, front construction and total front weight.

Required separately

This mechanism set is not a complete AVENTOS HS installation. The following components must be selected separately:

20S3500.06 standard lever-arm set, or the appropriate SERVO-DRIVE lever-arm set
20Q1061UN round cross-stabiliser rod, cut to the required cabinet width
20Q153ZN connecting set for internal cabinet widths of 1190 mm and above
Suitable front fixing brackets
Compatible AVENTOS HS cover-cap set

Standard and SERVO-DRIVE installations

The 20S2I00.05 lift mechanisms can form part of either a standard mechanical or correctly specified SERVO-DRIVE installation. The required lever arms, covers and electrical components depend on the selected system:

Use 20S3500.06 lever arms for a standard mechanical installation
Use 21S3500.01 lever arms and the appropriate electrical components for SERVO-DRIVE
The SERVO-DRIVE motor, switches, power supply and cabling are not included

Compatibility warning

Check the system generation before ordering: 20S2I00.05 belongs to the original AVENTOS HS range. It must not be confused with current-generation AVENTOS HS top mechanisms.

AVENTOS HS creates an up-and-over movement. It is not an AVENTOS HL parallel lift or an AVENTOS HF bi-fold lift. The original HS system requires the round 20Q1061UN cross stabiliser; do not substitute the oval AVENTOS HL stabiliser.

Product details

Brand: Blum
Range: Original AVENTOS HS
Component: Type I lift-mechanism set
Movement: Up-and-over lift for a single-piece front
Cabinet-height application: 676–800 mm
Maximum cabinet width: 1800 mm
Minimum internal cabinet depth: 276 mm
Manufacturer part number: 20S2I00.05
Hart SKU: HI20S2I00
Finish/colour: Zinc
Supplied as: One set containing two mechanisms and fixing screws
Complete lift system: No — lever arms and other system components are required separately

Browse the Blum AVENTOS lift systems and components or use the Blum Product Configurator to verify the complete installation specification.

TECHNICAL DETAILS

Length: 676mm
Finish: Zinc
Colour: Zinc
