PRODUCT DESCRIPTION
The Frelan J9507SSS Ball Bearing Hinge is a heavy-duty stainless steel hinge for demanding commercial doors. Built in premium Grade 316 stainless steel with a satin finish, it is Certifire approved, FD30/60 fire rated and supports doors up to 120kg (3 hinges).
KEY FEATURES
- Type: Ball Bearing Hinge
- Material Grade: 316 Stainless Steel
- Finish: Satin Stainless Steel
- Max Door Weight: 120kg (3 hinges)
- Fire Rating: FD30/60
- Certifire: Yes
- Hinge Grade: 13
- Corrosion Grade: 4
- Mechanical Warranty: 10 Years
- Use: Internal, Residential / Commercial
- UKCA / CE: Yes / Yes
- Fittings Included: Comes complete with 16 x wood screws (thread length: 28mm & thread diameter: 5mm)
DIMENSIONS
- Height: 102mm
- Width: 76mm
- Knuckle: 14.5mm
- Thickness: 3mm
To maintain compliance with the fire standard for these hinges, it is recommended that you fit these with the relevant intumescent pack (GRA 1 & GRA 1.2)
TECHNICAL DETAILS
- Application: Hinges
- Height: 102mm
- Length: 76mm
- Colour: Satin Stainless Steel
