Single Ball Catch – 13 mm diameter – brass finish

A single ball catch uses a sprung ball to engage with its receiving component as a suitable furniture door closes. Its compact mechanical action offers an alternative to magnetic retention when replacing or specifying a cabinet catch.

This brass finish option can be coordinated with nearby fittings. Compare the finish as well as the mechanism when matching existing furniture hardware, since similar colour names across different ranges can vary in tone.

Product details

• Product code: CA70612.
• Listed size: 13 mm diameter.
• Finish or colour: brass finish.

Selection and fitting

Match the body and receiving arrangement to the door and frame. Check the recess diameter, available depth and contact position before preparing the timber, then test engagement without forcing the door.

Choose the fitting for the complete installation, including the door, hinges and supporting material. Check that the mechanism has adequate clearance through its movement before marking or drilling fixing holes.
