The 102x152x3mm Satin Brass Parliament Ball Bearing Hinge is designed to allow doors to bypass deep reveals or wide skirting boards, enabling them to open a full 180 degrees. Built for durability, this hinge features ball bearings for smooth operation, making it suitable for both residential and commercial applications.

KEY FEATURES

• Type: Parliament Hinge

• Material Grade: 201 Stainless Steel

• Finish: Satin Stainless Steel

• Max Door Weight: 40kg (3 hinges)

• Corrosion Grade: 4

• Mechanical Warranty: 10 Years

• Use: Internal, Residential / Commercial

DIMENSIONS

• Width (W): 152mm

• Leaf (L): 26mm

• Cut-out (C): 100mm

• Thickness: 3mm
