Blum CLIP top BLUMOTION 107° Inset Screw-On Hinge – Onyx Black – 75B1750.ONS

Blum CLIP top BLUMOTION 107° Inset Screw-On Hinge – Onyx Black – 75B1750.ONS

Stock Code: HIO75B1750

£4.54 GBP
Sale
View full details

PRODUCT DESCRIPTION

Blum CLIP top BLUMOTION 107° Inset Hinge – Onyx Black

The Blum 75B1750.ONS is a fully cranked CLIP top BLUMOTION hinge for inset cabinet doors, where the closed door sits neatly inside the cabinet opening rather than covering the cabinet sides.

Its integrated BLUMOTION mechanism slows the door during closing, providing a controlled and quiet soft-close action. The soft-close function can be switched off on individual hinges when required, which is useful on smaller or lighter cabinet doors where several hinges are fitted.

With a minimum hinge-cup drilling depth of only 11.5mm, this hinge can be used with wooden cabinet fronts starting from 15mm thick. The 107° opening angle provides practical access for kitchen, bedroom and fitted-furniture cabinets.

The screw-on 35mm steel hinge cup is fixed directly to the back of the cabinet door. Blum’s CLIP connection then allows the hinge arm to attach to and release from the mounting plate without tools, making door installation, removal and adjustment considerably easier.

The onyx-black finish is particularly effective inside dark cabinets or on furniture where exposed nickel-coloured hardware would interrupt the overall design.

Key benefits

  • Designed for inset cabinet doors
  • Integrated BLUMOTION soft-close mechanism
  • BLUMOTION can be switched off on individual hinges
  • 107° opening angle
  • Suitable for wooden fronts starting from 15mm thick
  • Shallow 11.5mm hinge-cup drilling depth
  • Screw-on 35mm hinge cup
  • Sprung, self-closing action
  • Tool-free CLIP connection to the mounting plate
  • Three-dimensional door adjustment
  • Convenient spiral-screw depth adjustment
  • Coordinated onyx-black finish
  • Supplied as one hinge

The mounting plate is not included and must be ordered separately. For a coordinated dark installation, see the Blum 0mm onyx-black CLIP mounting plate. Confirm the required plate height and cabinet-fixing method before ordering.

Technical specifications

Specification Details
Hart stock code HIO75B1750
Blum part number 75B1750.ONS
Base part number 75B1750
Blum item number 02760874
Product range Blum CLIP top BLUMOTION
Application Inset cabinet doors
Hinge cranking Fully cranked
Opening angle 107°
Closing mechanism Sprung
Soft close Integrated, switchable BLUMOTION
Cup fixing Screw-on
Hinge-cup diameter 35mm
Minimum cup drilling depth 11.5mm
Cup fixing centres 45mm
Cup drilling distance 3–6mm
Minimum front thickness 15mm
Side adjustment ±2mm
Depth adjustment +3/−2mm
Height adjustment Through the selected mounting plate
Material All-metal hinge
Finish Onyx black
Mounting system Blum CLIP
Mounting plate Required; sold separately
Optional opening-angle stop 86° stop, part 74.1103
Quantity supplied One hinge
GTIN/EAN 9009494217674

Frequently Asked Questions

What is an inset cabinet hinge?

An inset hinge is designed for a door that closes inside the cabinet opening, leaving the front edges of the cabinet sides visible. This differs from an overlay hinge, where the door covers part or all of the cabinet side.

Does this hinge include soft close?

Yes. BLUMOTION soft close is integrated into the hinge cup and slows the door during closing. The mechanism can also be switched off on individual hinges if required.

What does screw-on mean?

Screw-on refers to the way the 35mm hinge cup is fixed to the cabinet door. It does not mean that the hinge arm screws directly to the mounting plate.

What is the minimum suitable door thickness?

Blum specifies this 107° hinge range for wooden cabinet fronts starting from 15mm thick. A trial installation is advisable for unusual materials, profiles or thicker fronts.

Is a mounting plate included?

No. The product is supplied as one hinge only. A compatible Blum CLIP mounting plate must be selected and purchased separately.

What drilling is required?

The door requires a 35mm hinge-cup hole with a minimum drilling depth of 11.5mm. The screw-fixing centres are 45mm, and the supported cup drilling distance is 3–6mm.

Can the opening angle be reduced?

Yes. The optional Blum 74.1103 opening-angle stop reduces the maximum opening angle to approximately 86°.

Is this hinge suitable for TIP-ON push-to-open doors?

No. This version has a closing spring and integrated BLUMOTION. Handleless TIP-ON doors normally require the appropriate unsprung, free-moving hinge instead.

Can the door be removed without unscrewing the hinge?

Yes. The CLIP mechanism allows the hinge arm to be detached from the mounting plate without tools, leaving the hinge cup fixed to the door.

TECHNICAL DETAILS

  • Application: Inset
  • Finish: Onyx Black
  • Colour: Onyx Black
  • Material: Steel
