The Blum AVENTOS HK-S 20K2E00 heavy-duty complete set combines compact cabinet installation with dependable upward-opening support. Designed for compatible single-piece fronts, its 960–2215 power-factor range is the strongest standard class in the HK-S family.

Integrated BLUMOTION provides smooth, quiet and controlled closing. When correctly selected and adjusted, the lift mechanisms allow the front to open with light operating forces and remain in a convenient intermediate position.

Compact lift system for low cabinet fronts

AVENTOS HK-S is suited to smaller wall cabinets, tall cabinets and storage above refrigerators or other appliances. The mechanisms fit compactly against the cabinet sides, leaving useful storage space while allowing the complete front to pivot upwards and clear of the working area.

The system operates without conventional cabinet hinges. Its standard opening angle is 107°, with separate 75° and 100° opening-angle stops available for installations beneath ceilings, cornices or other nearby obstructions.

Selecting the correct power factor

The Blum 20K2E00 mechanism covers a power-factor range of 960–2215. Calculate power factor by multiplying the cabinet height in millimetres by the complete front weight in kilograms, including double the handle weight. The 960–2215 range is a selection value and must not be presented as grams.

Correct power-factor selection and spring adjustment are essential for balanced operation and reliable stopping positions. Confirm the cabinet dimensions, total front weight and front construction before ordering. Follow current Blum planning guidance where an application falls within an overlapping or borderline range.

Orion dark grey coordinated finish

The functional lift mechanisms have a zinc finish and are concealed by Orion dark-grey covers. The deep neutral colour provides a coordinated contemporary appearance inside darker cabinet interiors while keeping the mechanism housings discreetly covered.

Key features

• Genuine Blum AVENTOS HK-S complete set
• Blum mechanism number 20K2E00
• Stock code HI20KSG
• Heavy-duty 960–2215 power-factor range
• Integrated BLUMOTION soft-close action
• Standard 107° opening angle
• For single-piece upward-opening cabinet fronts
• Suitable for cabinet heights up to 600mm
• Suitable for cabinet widths up to 1800mm
• Compact zinc-finished lift mechanisms
• Orion dark-grey mechanism covers
• Variable stopping positions
• No conventional cabinet hinges required

Product details

• Manufacturer: Blum
• Range: AVENTOS HK-S
• Mechanism number: 20K2E00
• Stock code: HI20KSG
• Mechanism type: Compact stay lift
• Duty class: Heavy duty
• Power factor: 960–2215
• Closing action: Integrated BLUMOTION
• Standard opening angle: 107°
• Cabinet height: Up to 600mm
• Maximum cabinet width: 1800mm
• Mechanism finish: Zinc
• Cover-cap colour: Orion dark grey

Set contents

This is a complete installation set containing the components required to fit the AVENTOS HK-S 20K2E00 system. Refer to the product packaging for the full component list. Optional opening-angle stops and any application-specific components not included in the set must be ordered separately.

To complete or extend your installation, browse the full Blum AVENTOS HK-S range, choose a compatible 75° or 100° opening-angle stop, or view the light grey version of this set.

Frequently asked questions

What is the Blum AVENTOS HK-S 20K2E00 used for?

It is a compact heavy-duty stay-lift system for compatible single-piece cabinet fronts that pivot upwards.

What does 960–2215 mean?

It is the mechanism’s power-factor range, not a weight in grams. Power factor is calculated using the cabinet height and complete front weight.

Does this set provide soft closing?

Yes. The standard 20K2E00 mechanism has integrated Blum BLUMOTION for smooth and controlled closing.

What is the standard opening angle?

The standard opening angle is 107°. Separate 75° and 100° opening-angle stops are available for installations with restricted overhead space.

Are conventional cabinet hinges required?

No. AVENTOS HK-S operates without conventional cabinet hinges, but the correct front-fixing components are required.

Is this the TIP-ON version?

No. This is the standard handle-operated BLUMOTION version. The TIP-ON mechanism has a different Blum article number.

What colour are the covers?

The visible covers have an Orion dark-grey finish. The functional lift mechanisms have a zinc finish.
