The Eclipse 73 Series Door Closer Size 3 with Cover 900mm in Silver delivers the controlled closing performance of a Size 3 overhead closer with the added benefit of a square cover plate that gives the unit a neater, more finished appearance on the door face. Supplied complete with cover, this is the ideal choice for installations where a clean, professional look is required alongside reliable door control.

The silver finish suits the widest range of door environments - from commercial offices and communal corridors to healthcare facilities and education settings - where a neutral, unobtrusive closer is required that blends with standard aluminium, stainless, or silver-toned door furniture. The cover plate conceals the closer body whilst the adjustable closing speed ensures consistent performance across varying door weights and traffic volumes.

Key Features:

• Size 3 closing force - suitable for doors up to 60kg
• 900mm closing arm - covers standard door widths
• Square cover plate included - conceals closer body for a neater finish
• Adjustable closing speed - configurable to suit door and user requirements
• Silver finish - neutral tone suited to a wide range of door environments
• Suitable for interior doors, communal corridors, and light commercial applications
• Supports fire door compliance in appropriate installations
• Screw-fix overhead installation

Technical Specifications:

• SKU: DF2012D
• Series: 73 Series
• Size: Size 3
• Maximum Door Weight: 60kg
• Arm Length: 900mm
• Finish: Silver
• Material: Aluminium / Steel
• Includes: Closer body, closing arm, square cover plate
• Fixing: Screw-fix overhead mount
• Application: Interior doors, fire doors, offices, communal corridors, healthcare, education

Fix the closer body to the top of the door face using the supplied screws and template. Attach the closing arm to the frame bracket. Fit the square cover plate over the closer body and secure as directed. Adjust the closing speed and latch action valves with a hex key. Full fitting instructions and a fixing template are supplied.
