Name: TECTUS TE541 3D FVZ Concealed Door Hinge – Polished Brass
Brand: SIMONSWERK UK LTD
SKU: HIB217B
Price: 152.89 GBP
Availability: InStock

PRODUCT DESCRIPTION

TECTUS TE541 3D FVZ in Polished Brass

The TE541 3D FVZ in Polished Brass is a premium SIMONSWERK concealed door hinge for carefully specified architectural installations. It is hidden when the door is closed, keeping exposed hinge knuckles out of the finished door line.

FVZ identifies preparation for recessed frames. Use the exact FVZ mortise and frame-facing dimensions rather than the standard hinge preparation.

The polished brass finish brings a warm, reflective accent to the hinge when the door is open. It suits schemes that coordinate visible details with polished brass handles and fittings, while the closed door retains a clean, uninterrupted appearance.

Model-specific technical information

Exact model: TE541 3D FVZ
Version: FVZ
Finish: Polished Brass (SW 030)
Reference capacity: up to 100 kg using two hinges on a 1 m × 2 m door leaf, subject to manufacturer technical conditions
Minimum door thickness: 42.0 mm
Frame width: 28 mm; hinge length: 185 mm
Country of origin: Germany
SIMONSWERK manufacturer part number: 5 400631 0 03002
Stock code: HIB217B
Quantity supplied: one hinge

comfortable 3D adjustment (side ± 3.0 mm, height ± 3.0 mm, compression ± 1.0 mm). Follow the manufacturer’s sequence when setting alignment.

Optional routing accessories

The manufacturer lists 52506825 (frame, step 3), 52509425 (frame / door, step 1), 52509435 (frame / door, step 2), 52509445 (door, step 3), 52511695 (frame, step 3, without cladding) for this exact version. Templates require the appropriate universal milling frame when used with the SIMONSWERK jig system. Jigs, templates and milling frames are optional accessories, purchased separately from the hinge.

Universal milling frame: check the specified frame and supplied template components before ordering.

Fire-door selection

Suitability for a fire door depends on the complete door construction and supporting certification. Follow the tested assembly and installation instructions, including its specified intumescent protection. Do not transfer a standard model’s approval or kit requirements to this version.

Installation guidance and related hinges

Read the SIMONSWERK TE541 3D FVZ technical information and routing instructions before preparation. Check door dimensions, weight, frame construction and any receiver capacity or closer forces. The quoted load is a reference for two hinges, not one hinge. At an opening position of 180°, additional door fixing may be needed.

Browse the TECTUS concealed hinge range for related models and finishes, or contact Hart Wholesale with the exact door details.

Is this the same as a standard TE541 hinge?

Order by the full model and version name: TE541 3D FVZ. Specialist versions can have different preparation, capacity and accessory requirements. Match the manufacturer number before replacing an existing hinge.

What does one order unit contain?

One TE541 3D FVZ hinge in Polished Brass, SW 030. Optional routing equipment and separately listed installation accessories are purchased separately.

How do I confirm the correct part?

Use stock code HIB217B, manufacturer part number 5 400631 0 03002, the full version name and SW 030. A similar appearance alone does not establish interchangeability.
