Blum 71B3690 CLIP top BLUMOTION 110° Dual Half-Overlay INSERTA Hinge | Onyx Black

Blum 71B3690 CLIP top BLUMOTION 110° Dual Half-Overlay INSERTA Hinge | Onyx Black

Stock Code: HIO71B3690

£3.97 GBP
Sale
View full details

PRODUCT DESCRIPTION

Blum 71B3690 CLIP top BLUMOTION 110° dual half-overlay INSERTA hinge – Onyx Black

The Blum 71B3690 combines integrated BLUMOTION soft close with fast, tool-free INSERTA installation and an Onyx Black finish. Its 110° opening angle and half-cranked hinge arm suit dual or half-overlay applications where two cabinet doors share one central partition.

Each door covers only part of the partition edge, allowing both fronts to open independently. BLUMOTION provides controlled closing, and the damping function can be deactivated when less resistance is needed for a smaller or lighter door.

Technical details

  • Blum part number: 71B3690
  • Hart Wholesale SKU: HIO71B3690
  • Type: CLIP top BLUMOTION concealed hinge
  • Application: dual/half overlay
  • Hinge arm: half cranked
  • Opening angle: 110°
  • Closing action: spring closing with integrated, deactivatable BLUMOTION
  • Hinge-cup fixing: INSERTA tool-free fixing
  • Door-to-cabinet connection: CLIP mechanism
  • Adjustment: three-dimensional with a suitable mounting plate, including spiral depth adjustment
  • Material: steel
  • Finish: Onyx Black
  • Quantity: one hinge
  • Mounting plate: supplied separately

Half-overlay planning

A half-overlay hinge is used when two cabinet doors share the same central partition. The half-cranked arm positions each door so both can close correctly while covering only part of the shared panel edge. This differs from a full-overlay hinge, which is normally used on an outside cabinet side.

Planning and fitting

INSERTA requires correctly prepared door drillings. The hinge cup locks into the prepared fixing pattern without conventional cup-fixing screws or insertion machinery. The CLIP mechanism then connects the hinge arm to a compatible mounting plate without tools.

A compatible Blum CLIP mounting plate must be ordered separately. Select the plate height according to the cabinet construction, drilling distance and required half overlay.

For the verified nickel counterpart, see the Blum 71B3690 dual half-overlay INSERTA hinge. For a conventional screw-fixed cup, compare the Blum 71B3650 half-overlay screw-on hinge. Browse the Blum CLIP top half-overlay hinge collection.

Matching components

The mounting plate, cabinet fixings, cover caps and drilling equipment are supplied separately. This listing contains one hinge.

Frequently Asked Questions

What is a half-overlay hinge?

It is designed for two doors sharing a central cabinet partition. Each door overlays approximately half of the panel edge.

Does the 71B3690 include a mounting plate?

No. It is supplied as one hinge, with the compatible Blum CLIP mounting plate sold separately.

What does INSERTA mean?

INSERTA is Blum’s tool-free hinge-cup fixing system. The hinge locks into correctly prepared door drillings without conventional fixing screws.

Can the BLUMOTION soft-close function be switched off?

Yes. The integrated BLUMOTION mechanism can be deactivated when required, particularly for smaller or lighter doors.

What is the difference between 71B3690 and 71B3650?

Both are 110° half-overlay BLUMOTION hinges in Onyx Black. The 71B3690 uses tool-free INSERTA cup fixing, while the 71B3650 has a screw-on cup.

Is one hinge supplied?

Yes. This listing is for one hinge. Mounting plates and other installation components are supplied separately.

TECHNICAL DETAILS

  • Application: Dual
  • Finish: Onyx Black
  • Colour: Onyx Black
  • Material: Steel
