Blum CLIP top BLUMOTION 110° Overlay Knock-In Hinge Onyx Black | 71B3580

Blum CLIP top BLUMOTION 110° Overlay Knock-In Hinge Onyx Black | 71B3580

Stock Code: HIO71B3580

£3.22 GBP
Sale
View full details

PRODUCT DESCRIPTION

Blum CLIP top BLUMOTION 110° Overlay Knock-In Hinge – Onyx Black

The Blum 71B3580 CLIP top BLUMOTION hinge combines a premium Onyx Black finish with Blum's integrated soft-close technology. Its 110° opening angle and straight hinge arm make it suitable for standard overlay cabinet-door applications.

BLUMOTION is built into the hinge cup, producing a smooth and controlled closing action without requiring a separate soft-close adapter. The BLUMOTION function can be deactivated on individual hinges when used with smaller or lighter doors.

This version has a knock-in hinge cup. Installation requires one 35mm cup drilling and two 8mm fixing holes on 45mm centres. The hinge is normally pressed into the prepared door using suitable Blum insertion equipment.

Key features

  • Genuine Blum CLIP top BLUMOTION concealed cabinet hinge
  • Blum part number: 71B3580
  • Hart stock code: HIO71B3580
  • Premium Onyx Black finish
  • 110° cabinet-door opening angle
  • Straight arm for overlay applications
  • Integrated BLUMOTION soft-close mechanism
  • BLUMOTION can be deactivated for smaller or lighter doors
  • 35mm steel knock-in hinge cup
  • Tool-free CLIP attachment to a compatible mounting plate
  • Three-dimensional adjustment when used with a suitable mounting plate
  • Supplied as one hinge

Technical specifications

Manufacturer Blum
Blum part number 71B3580
Hart stock code HIO71B3580
EAN / GTIN 9009494201680
Hinge system CLIP top BLUMOTION
Application Overlay cabinet door
Opening angle 110°
Closing action Spring closing with integrated, deactivatable BLUMOTION
Cup fixing Knock-in
Hinge cup diameter 35mm
Cup drilling depth 13mm
Fixing-hole diameter 8mm
Fixing-hole centres 45mm
Fixing-hole offset 9.5mm from the cup centreline
Cup drilling distance 3–7mm
Side adjustment ±2mm
Depth adjustment +3mm / −2mm
Material Steel
Finish Onyx Black
Quantity One hinge
Mounting plate included? No – order separately

Installation requirements

Bore a 35mm hinge-cup hole to a depth of 13mm, together with two 8mm fixing holes positioned on 45mm centres. The cup drilling distance can be set between 3mm and 7mm according to the door, cabinet and overlay requirements.

The knock-in cup should be pressed into the prepared door using appropriate insertion equipment. Once installed, the hinge connects to a compatible Blum mounting plate using the tool-free CLIP mechanism.

Please note: the mounting plate is not supplied with this hinge. Select the correct plate height and fixing method for the required cabinet construction and door overlay.

Compatible mounting plates and accessories

Alternative Onyx Black fixing options

Browse the complete Blum CLIP top hinge collection or view all Blum furniture fittings.

Frequently asked questions

Is a mounting plate included?

No. HIO71B3580 is supplied as one hinge only. A compatible Blum CLIP mounting plate must be ordered separately.

What does knock-in mean?

Knock-in describes the door-side hinge-cup fixing. The hinge has expanding dowels that fit into two prepared 8mm holes alongside the 35mm cup drilling. Suitable insertion equipment is recommended.

Is the complete hinge installation tool-free?

No. The knock-in cup requires prepared holes and appropriate insertion equipment. After installation, the hinge clips onto its mounting plate without tools using Blum's CLIP mechanism.

Can the BLUMOTION soft close be switched off?

Yes. Integrated BLUMOTION can be deactivated on individual hinges where reduced damping is required, particularly on smaller or lighter cabinet doors.

Can the opening angle be reduced?

Yes. The compatible Blum 70T3553 opening-angle stop reduces the opening angle from 110° to approximately 86°.

What drilling pattern is required?

The hinge requires a 35mm cup hole, 13mm deep, plus two 8mm fixing holes on 45mm centres. The permitted cup drilling distance is 3–7mm.

TECHNICAL DETAILS

  • Application: Overlay
  • Size: 110° opening, 35mm cup, 45mm centres
  • Diameter: 35mm
  • Finish: Onyx Black
  • Colour: Onyx Black
  • Code: HIO71B3580
  • Material: Steel
