Blum CLIP top BLUMOTION 110° Overlay INSERTA Hinge Onyx Black | 71B3590

Blum CLIP top BLUMOTION 110° Overlay INSERTA Hinge Onyx Black | 71B3590

Stock Code: HIO71B3590

£3.77 GBP
Sale
View full details

PRODUCT DESCRIPTION

Blum CLIP top BLUMOTION 110° Overlay INSERTA Hinge – Onyx Black

The Blum 71B3590 CLIP top BLUMOTION hinge is a premium concealed cabinet hinge combining integrated soft close, rapid INSERTA installation and a distinctive Onyx Black finish. Its straight hinge arm is designed for overlay cabinet-door applications, while the 110° opening angle suits a wide range of kitchen, bedroom and fitted-furniture installations.

BLUMOTION is integrated directly into the hinge, providing a smooth, controlled closing action without needing a separate soft-close adapter. The damping function can be deactivated on individual hinges when less closing resistance is required for smaller or lighter doors.

The INSERTA hinge cup locks into the prepared door without fixing screws. Once the 35mm cup hole and two 8mm fixing holes have been accurately drilled, the built-in INSERTA lever secures the hinge cup and its expanding dowels in position. This provides fast, consistent installation and allows the hinge to be removed without damaging the door.

Key features

  • Genuine Blum CLIP top BLUMOTION concealed cabinet hinge
  • Blum part number: 71B3590
  • Hart stock code: HIO71B3590
  • Premium Onyx Black finish
  • 110° opening angle
  • Straight hinge arm for overlay cabinet doors
  • Integrated BLUMOTION soft-close mechanism
  • BLUMOTION can be deactivated for smaller or lighter doors
  • Tool-free INSERTA hinge-cup locking
  • No hinge-cup fixing screws required
  • 35mm steel hinge cup
  • Tool-free CLIP connection to a compatible mounting plate
  • Three-dimensional adjustment with the appropriate mounting plate
  • Supplied as one hinge

Technical specifications

Manufacturer Blum
Blum part number 71B3590
Hart stock code HIO71B3590
EAN / GTIN 9009494216721
Hinge system CLIP top BLUMOTION
Application Overlay cabinet door
Opening angle 110°
Closing mechanism Spring closing with integrated, deactivatable BLUMOTION
Hinge-cup fixing INSERTA tool-free locking
Hinge-cup diameter 35mm
Cup drilling depth 13mm
Fixing-hole diameter 8mm
Fixing-hole centres 45mm
Fixing-hole offset 9.5mm from the cup centreline
Cup drilling distance 3–7mm
INSERTA flange dimensions 57 × 27.5 × 6.4mm
Side adjustment ±2mm
Depth adjustment +3mm / −2mm
Height adjustment Via the selected mounting plate
Material Steel
Finish Onyx Black
Quantity One hinge
Mounting plate included? No – order separately

INSERTA installation

Prepare one 35mm hinge-cup hole to a depth of 13mm, together with two 8mm fixing holes positioned on 45mm centres. The fixing holes are offset 9.5mm from the centreline of the cup drilling.

Place the INSERTA hinge cup into the prepared drilling and operate the built-in locking lever. This expands the integrated fixing dowels and secures the hinge without separate screws or insertion machinery.

The hinge then clips onto a compatible Blum mounting plate using the tool-free CLIP connection. Side, depth and height adjustments can be completed after the door has been fitted.

Please note: a compatible Blum CLIP mounting plate is required and must be ordered separately. The correct plate height depends on the cabinet construction, drilling distance and required door overlay.

Compatible Onyx Black mounting plates

A 0mm plate is commonly used for standard overlay applications, but the required plate height should always be checked against the door overlay and cabinet design.

Compatible opening-angle stop

Where the cabinet door must be prevented from opening fully, use the Blum 70T3553 opening-angle stop. This reduces the hinge opening angle from 110° to approximately 86°, helping prevent the door or handle from contacting an adjacent wall, cabinet or appliance.

Alternative Onyx Black cup fixings

Browse the complete Blum INSERTA hinge collection, the full Blum CLIP top hinge range or view all Blum furniture fittings.

Frequently asked questions

Is the mounting plate included?

No. HIO71B3590 is supplied as one hinge. A compatible Blum CLIP mounting plate must be selected and purchased separately.

What does INSERTA mean?

INSERTA is Blum's tool-free door-side hinge-cup fixing. A built-in lever expands the integrated dowels inside two prepared 8mm holes, securing the hinge without separate fixing screws.

Does INSERTA require additional parts?

No separate INSERTA parts are required. The INSERTA locking mechanism and fixing dowels are built into the hinge. Only the cabinet-side mounting plate is separate.

What drilling pattern is required?

Installation requires a 35mm cup hole, 13mm deep, plus two 8mm fixing holes on 45mm centres. The permitted cup drilling distance is 3–7mm.

What is the difference between INSERTA and knock-in?

Both versions use a 35mm cup and two 8mm fixing holes. INSERTA is locked into the door using the hinge's built-in lever, while a knock-in hinge is normally pressed into the drilling using appropriate insertion equipment.

Can BLUMOTION be switched off?

Yes. The integrated BLUMOTION function can be deactivated on individual hinges where less damping is required, particularly with smaller or lighter doors.

Can the opening angle be reduced?

Yes. The compatible Blum 70T3553 opening-angle stop reduces the opening angle from 110° to approximately 86°.

TECHNICAL DETAILS

  • Application: Overlay
  • Size: 110° opening, 35mm cup, 45mm centres
  • Diameter: 35mm
  • Finish: Onyx Black
  • Colour: Onyx Black
  • Code: HIO71B3590
  • Material: Steel
